ATLAS COPCO SERVICE KITS - FEATURES

* Everything you need to maintain your screw compressor is in one single kit
* Cost effective solution
* Assurance of high quality components
* Easy to use
* Higher efficiency
* Service kits are available at our official service organization and partners
* Low internal logistic costs
* Longer life Time of your screw compressor

EWD330 - Electronic Water Drain Kit

EWD330 Kits solves all compressed air condensate discharge problems, even with heavily contaminated systems. The water separators and drains offer safe, dependable and economical condensate management. EWD Kit Part numbers 1622855183, 2901063320, 2901067300, 2901067300, 1622855181, 2901146551.

Unloading Valve Kit - Intake Valve Kit

It blows off the pressure inside the discharge pipe when the compressor stops.(There is another type of unloader valve, which can be found at the inlet of rotary screw compressors, also called inlet valve or loading valve). On smaller units, this valve is often mounted on or inside the pressure switch. When the pressure switches off the compressor, the unloader valve is also actuated. The check valve is often located right at the point where the compressor discharge pipe is connected to the storage tank. From this check valve, a small tube or pipe runs to the unloader valve on the pressure switch. Unloading valves is controlled by air pressure from a small pilot valve. unloading valve kit part numbers: 2901000201, 2902016100, 2901162200, 2901146300, 2901029801,

MPV Kit (Minimum Pressure Valve Kit)

The minimum pressure valve can be found on rotary screw compressors. In this valves are sits on top of the separator vessel. Atlas copco minimum pressure valve-mpv kit part numbers: 2901145300, 2901099700, 2901109500, 2901906000, 1625005540, 2901139900, 2901000600, 2906020100, 2205490594. This minimum pressure valve has two functions. Actually, it is two valves in one:

Thermostatic Valve Kit

Thermostatic Valves to keep your air compressor machine running efficiently, effectively and operating at full capacity. The function of the Thermostatic Valve is the regulation of the oil flow in oil-injected screw compressors. Thermostatic Valve kit part numbers: 162270640, 2901161600, 2901161700, 1622706404, 2901141400, 2901109500, 2901006800, 2901007400, 1619733300.

Oil Stop Check valve kit

A check valve is a fitting that allows compressed air to flow through it, but only one way. If the air tries to flow back up through the check valve, the valve flapper or similar device shuts, and air cannot escape. Compressed air flows into the compressor tank from the pump through the tank check valve fitting.
Atlas copco oil stop check valve kit Part numbers:2901021704, 2901196000, 2901201800, 2901108401, 2906009400, 1625170485, 2901021700, 2901021702.

ATLAS COPCO COMPRESSOR KITS
